Automatic Paint Brush Making Machine

1>Size:1″,1.5″,2″,2.5″,3″,4″,5″,thickness:8mm to 25mm ;
2>Speed:1200~1400pcs per hour.
3>Power:220V, 50Hz, single phase,3kw; Air power:0.5m³/minutes
5>Crate Size:4300*1600*1750mm
6>Worker: 2
7>Automatic filling filament or bristle into ferrule operated through 2 operating personnel.
8>Mechnical Construction
One station to put the plastic wedges, Max. single layer thickness:8mm; multi layers as per requirements.
9>Control Way: Omron PLC
Airtac Pneumatic Parts, Schneider Low voltage electrical appliances, MCGS touch screen
